Banded-Spine Dust Adapter
Created 1 months ago
Description
A high-traction, banded transition piece engineered to bridge the gap between standard shop vacuums and precision power tools. Its ridged silhouette evokes a segmented mechanical spine, providing a rugged exterior grip while handling rigorous suction demands. The stepped-bore architecture utilizes a 31.5mm outer diameter to nest seamlessly inside a primary 32mm vacuum line, while the 25.5mm internal channel slides definitively over standard power tool exhaust ports.
Engineered Flow Traits
- Clamp-Lock Ribs: Circumferential exterior spines deliver an aggressive mechanical hold for metal hose clamps, practically eliminating slippage under vibration.
- Arrestor Flange: An integrated mid-line collar acts as a physical backstop, ensuring both hose and tool seat to the strict designated depth.
- Continuous Draft: The straight internal channel bridges the differing equipment sizes without choking off the volumetric air flow.
Photos
Technical views
